Traveller T08

Cottage Style Modular Cabin

The Rituheadways Traveller T08 offers a pitched-roof cabin with an illustrated bedroom, kitchenette and bathroom layout. Explore it for private stays, farm stays and hospitality concepts seeking a cottage-style exterior.

Product Specifications

Dimensions	9,300 × 3,000 × 3,550 mm, length × width × height.
Carpet and Built Up Area	Brochure cover area: 28 m², approximately 301 sq ft. Net carpet area is available on request.
Capacity	Occupancy or seating capacity depends on the final layout and intended use. Contact our team for the capacity of your selected configuration.
Layout	The single-level plan shows a bed at one end, a kitchenette counter along the wall and bathroom facilities at the opposite end.
Exterior	The brochure presents a pitched roof, light exterior walls and substantial bedroom-side glazing. Roof colour and finishes follow the selected available package.
Interior	The plan combines sleeping space and kitchenette facilities in a single-level arrangement with a separate bathroom.
Materials	Glass and cement fibreboard form part of the supplied material specification. Sanitary fittings and air-conditioning are provided according to the agreed fit-out.
Structure	Galvanised tubular frame structure.
Insulation	Polyurethane foam insulation with glass wool or rock wool, according to the selected specification. Thickness and performance values are available on request.
Bathroom Specification	The plan shows WC, basin and shower facilities. Final fixture details and water-heating provisions are confirmed in the specification.
Kitchen Specification	The layout shows a kitchenette counter with sink and cooking-position symbols. Cabinet and sink provisions are included according to the agreed package; appliances require confirmation.
Electrical	Request the electrical schedule for the selected model, including supply requirements, connected load, lighting and socket provisions.
HVAC	Air-conditioning is provided according to the selected package. Unit capacity and ventilation provisions are confirmed in the final specification.
Customisation Options	Explore the brochure layout and discuss compatible interior, exterior and fit-out changes with our team. Available options are confirmed for the selected model.
Installation	Factory-prepared unit for dispatch. Site support, lifting access, positioning and utility connections are planned for the project location and agreed delivery scope.
Transportation	Transportation is charged separately, based on the project location and delivery requirements.
Warranty	One-year warranty, subject to the agreed scope and warranty terms.
Approximate Pricing	Request the current model-specific price. Final pricing depends on the selected configuration and agreed inclusions. Transportation is charged separately.
Enquiry	Call or WhatsApp +91 9592226267 to discuss this model, availability and a project quotation. Enquire on WhatsApp
Downloadable Specification Sheet	Download the product brochure to view the model and illustrated layout. Request the detailed model specification from our team. Download Brochure

Areas described as external footprint or brochure cover area are not net carpet areas. Final drawings determine usable internal area, installation dimensions and the selected fit-out.

Explore Traveller T08

View the exterior and interior gallery, review the floor plan and explore the available 3D product view to understand the space before enquiring.

VIEW FLOOR PLAN EXPLORE IN 3D DOWNLOAD PRODUCT BROCHURE REQUEST MODEL SPECIFICATIONS

Plan Your Traveller T08 Project

Share your project location, intended use, number of units and preferred configuration. Our team will discuss the model, fit-out and delivery requirements for your site.
